NC/CNC SF 48-1500 CNC
CNC lathe
 Specifications |
|
| Catalog No. : | 7947 |
| Type: | SF 48-1500 CNC |
| Producer: | Fermat |
| Made in: | 2008 |
| Characteristic: | |
| Control system: Fagor 8055 TC | |
| Maximum length of the turning: 1500 mm | |
| Max. turning diameter: 460 mm | |
| Turning diameter over bed (max): 475 mm | |
| Turning diameter over cross slide (max): 240 mm | |
| Spindle bore: 51 mm | |
| Maximum rotary speed of the spindle: 4500 1/min | |
| Power of the spindle: 7.5/11 kW | |
| Length: 3530 mm | |
| Width: 1935 mm | |
| Height: 2022 mm | |
| Weight: 3450 kg | |
| Equipment: | |
| 8-position turret tool head | |
