NC/CNC FP 4 MA
CNC milling machine
 Specifications |
|
| Catalog No. : | 9073 |
| Type: | FP 4 MA |
| Producer: | DECKEL |
| Made in: | 1998, GO 2003 |
| Characteristic: | |
| Control system: HEIDENHAIN | |
| Length of the working table: 800 mm | |
| Width of the working table: 465 mm | |
| Maximum rotary speed of the vertical spindle: 4000 1/min | |
| X-Axis travels: 465 mm | |
| Y-Axis travels: 370 mm | |
| Z-Axis travels: 380 mm | |
| Machine height: 1734 mm | |
| Machine length: 2000 mm | |
| Machine width: 1600 mm | |
| Machine weight: 1720 kg | |
