NC/CNC PICOMAX 56 TOP
CNC milling machine
 Specifications |
|
| Catalog No. : | 8301 |
| Type: | PICOMAX 56 TOP |
| Producer: | FEHLMANN |
| Made in: | 2013 |
| Characteristic: | |
| Control system: Heidenhain TNC 620 | |
| Length of the working table: 908 mm | |
| Width of the working table: 480 mm | |
| Milling spindle speed: 50-12000 1/min | |
| Power of the spindle drive: 9.5 kW | |
| X-Axis travels: 500 mm | |
| Y-Axis travels: 400 mm | |
| Z-Axis travels: 400 mm | |
| Taper: ISO/SK 30 | |
| Maximum number of tools: 20 | |
| Machine height: 2500 mm | |
| Machine length: 1900 mm | |
| Machine width: 1700 mm | |
| Machine weight: 3050 kg | |
| Equipment: | |
| Manual tool change | |
