NC/CNC SE 520 NUMERIC
CNC lathe
 Specifications |
|
| Catalog No. : | 7558 |
| Type: | SE 520 NUMERIC |
| Producer: | TRENS |
| Made in: | 2005 |
| Characteristic: | |
| Maximum-turning length: 1500 mm | |
| Turning diameter over bed (max): 520 mm | |
| Turning diameter over cross slide (max): 290 mm | |
| Workpiece weight: 1000 kg | |
| Workpiece weight between centers (max): 1000 kg | |
| Spindle taper: Morse 5 | |
| Chuck diameter: 315 mm | |
| Maximum workpiece dimensions: 285 x 1500 mm | |
| Length: 3290 mm | |
| Width: 1560 mm | |
| Height: 1800 mm | |
| Weight: 2900 kg | |
| Equipment: | |
| Chuck | |
| Tool holders | |
